| Model | 60 M2 |
| Innerside Dimension(mm)L×W×H | 12000x5000x3000 |
| Painting Room Dimension(mm)L×W | 6000x5000x3000 |
| Drying Room Dimension(mm)L×W | 6000x5000x3000 |
| Incoming Door Dimension(mm)W×H | 1900×2300 |
| Delivery Door Dimension(mm)W×H | 1900×2300 |
| Air Capacity(m3/h) | 20000 |
| Air Speed(m/s) | 0.2-0.3 |
| Ventilation Rate(Times/Hour) | 255 |
| Fan Power(KW) | 2*1.5kw 2*2.2KW |
| Wall Panels | Panels 50mm EPS colorful steel skin panel, steel 0.4mm thick,12kg/cbm and flame-resisting EPS, tongue groove style, compound construction, anti-flame and heat-insulation. |
| Grilles | 10#channel steel， 6M2 |
| Lighting | 4*4*36W lamp,Illuminance exceeding 750LUX, non explosive |
| Infrared Heating Tubes | 24 pieces ×1 KW infrared light heater ,anti-explosion |
| Generator Setting Type | Upper intake air |
| Intake Air Fan For painting room | 2×1.5KW double-intake centrifugal fans, air capacity: 20000m³/h |
| Exhaust Fan For painting room | 2×2.2 KW with water curtain booth. |
| Filter System | Intake air: pre-filter, high efficiency filter(ceiling filter) Exhaust air: water curtain filtering |
