Safety secondary turn plate electro-hydraulic scissor lift LS-4000
Specification:
Lifting weight
|
4000kg |
Secondary lifting weight
|
3500kg |
Initial height of platform
|
240mm |
Host lifting height
|
1850mm |
Second lifting height
|
450mm |
Host lifting bridge length
|
4500mm |
Second lifting bridge length
|
1400mm |
Host lifting bridge width
|
620mm |
Second lifting bridge width
|
550mm |
Motor power
|
3.0kw |
Air pressure
|
0.6-0.8mpa |
Oil pressure
|
25mpa |
Voltage
|
380v /220v |
Equipment weight
|
2.1t |
Unlock method
|
pneumatic unlock |
Packing size
|
4650*550*750（mm）*2pcs
650✘540✘1050(mm) |
Features
1.Super low platforms(240mm minimum height)and ramps meet various chassis height of vehicles,small space to take and installed directly on the ground.
2.The surface adopts the shot blasting, degrease, parkerising,static powder coating, so it is of anti-erosion, good adhesion and high hardness..
3.Double tandem synchronous balanced cylinders and four cylinders driving ensures synchronous lifting of platforms,the 4T lifting capacity can match various vehicles repair requirement.
4.The lift is equipped with secondary lifting trolley, moving flexibly,controlled by manual button and remote. Extended side slide adapts to vehicles of various wheelbases. The lift can be used for SUV and business vehicles.
5.The use of mechanical safe lock, explosion -proof valves and self-lock of hydraulic systems ensure a safe work.
6.Integrated PLC computer controller features self-testing function, offering guidance in eliminating faults and ensure safe voltage.
7.Imported oil seals from Italy flat combination valve block structure and dual oil circuits can also be quickly leveling,avoiding oil leakage inside.
8.Decline buzzing alert and light alert reduce the possibility of safety accidents.
