Automatic pneumatic safety lock scissor lift LS-3000C
Specification:
Lifting weight
|
3000kg |
Lifting height
|
1200mm |
Minimum height
|
110mm |
Table length
|
1400-1940mm |
Table width
|
530mm |
Lifting and lowering time
|
60-50S |
Air pressure
|
0.3mpa |
Oil pressure
|
20mpa |
Motor power
|
2.2kw |
Voltage
|
380v /220v |
Unlock method
|
pneumatic unlock |
Weight
|
590kg |
| Packing size |
2000*1630*260（mm)
650*540*1050(mm) |
Features:
●Surface mounting at min height of 110mm.
●Mechanical safety lock engaged automatically, with electrical release when lowering.
●All pivot joints made with self-lubrication bushing ensure long service life.
●Optional mobile kit for easy moving.
●Extendable platform suitable for more long chassis vehicles.
●The middle steel bar connects two platforms ensure stability and synchronization.
●CE standard.
